ASTM A312 316Ti Seamless Tube
-
Type: Seamless, Welded
OD: 1/2"-48"
Thickness: SCH5-SCHXXS
Length: 0-12M, Customized
Process: Hot/Cold Rolled,Hot work,Cold drawn
ASTM A312 316Ti Seamless Tube, 316Ti Stainless Steel Pipes, 316Ti Stainless Steel Seamless Pipe, SS 316Ti Welded Pipe, 316Ti Stainless Steel ERW Pipe, ASTM A312 TP316TI Stainless Steel Seamless Pipes, ASTM A312 Grade 316Ti Stainless Steel Pipes.
ASTM A312 316Ti Seamless Tube:
316ti is a titanium stabilized 316 alloy. The ASTM A312 316Ti Seamless Tube is designed with an excellent tensile strength of minimum 75Ksi and yield strength of 30Ksi. 316Ti Stainless Steel Pipes can be easily elongated up to 54% and still possess good hardness. The Stainless Steel 316Ti Pipe has excellent pitting and creep resistance. These 316Ti Stainless Steel Seamless Pipes possess good density up to 72 degrees F.
Apart from that they have a good melting range of 1345-1440 degrees C.
The SS 316Ti Tubes can work at extreme temperatures ranging up to 1800
degrees C. These SS 316Ti Welded Pipes have a higher stress rupture as
the temperature starts increasing. We are the top stockist of 316Ti
Stainless Steel ERW Pipe in China. Our institution thrives to produce
the best products at feasible rates.
The ASTM A312 316Ti Seamless Tube can be used for extended periods at elevated temperatures without compromising its corrosion resistance. 316Ti has equvilent corrosion resistance to sensitisation as the low carbon version 316L.
ASTM A312 TP 316Ti Welded Pipe Dimension Chart
Nominal size in inches | Outside diameter in inches | Outside diameter in mm | Wall thickness in inches | Wall thickness in mm | Weight [lbs/feet] | Weight [kg/meter] |
1/8 6 | 0.41 | 10.3 | 0.068 | 1.73 | 0.24 | 0.37 |
1/4 8 | 0.54 | 13.7 | 0.088 | 2.24 | 0.42 | 0.63 |
3/8 10 | 0.68 | 17.1 | 0.091 | 2.31 | 0.57 | 0.84 |
1/2 15 | 0.84 | 21.3 | 0.109 | 2.77 | 0.85 | 1.27 |
3/4 20 | 1.05 | 26.7 | 0.113 | 2.87 | 1.13 | 1.69 |
1 25 | 1.32 | 33.4 | 0.133 | 3.38 | 1.68 | 2.5 |
1 1/4 32 | 1.66 | 42.2 | 0.14 | 3.56 | 2.27 | 3.39 |
1 1/2 40 | 1.9 | 48.3 | 0.145 | 3.68 | 2.72 | 4.05 |
2 50 | 2.375 | 60.3 | 0.154 | 3.91 | 3.65 | 5.44 |
2 1/2 65 | 2.875 | 73 | 0.203 | 5.16 | 5.79 | 8.63 |
3 80 | 3.5 | 88.9 | 0.216 | 5.49 | 7.58 | 11.29 |
3 1/2 90 | 4 | 101.6 | 0.226 | 5.74 | 9.11 | 13.57 |
4 100 | 4.5 | 114.3 | 0.237 | 6.02 | 10.79 | 16.07 |
5 125 | 5.563 | 141.3 | 0.258 | 6.55 | 14.62 | 21.77 |
6 150 | 6.625 | 168.3 | 0.28 | 7.11 | 18.97 | 28.26 |
8 200 | 8.625 | 219.1 | 0.322 | 8.18 | 28.55 | 42.55 |
10 250 | 10.75 | 273 | 0.365 | 9.27 | 40.48 | 60.31 |
12 300 | 12.75 | 323.8 | 0.406 | 10.31 | 53.52 | 79.73 |
14 350 | 14 | 355.6 | 0.437 | 11.13 | 54.57 | 94.55 |
16 400 | 16 | 406.4 | 0.5 | 12.7 | 82.77 | 123.3 |
18 450 | 18 | 457 | 0.562 | 14.27 | 104.67 | 155.8 |
20 500 | 20 | 508 | 0.594 | 15.09 | 123.11 | 183.42 |
24 600 | 24 | 610 | 0.688 | 17.48 | 171.29 | 255.41 |
32 800 | 32 | 813 | 0.688 | 17.48 | 230.08 | 342.91 |
