Hastelloy G-30 Plate Sheet

0086-17695531343

sales@tsingshan-scaffold.com

Hastelloy G-30 Plate, DIN 2.4603 Plate, Alloy G30 Sheet, 2.4603 Hastelloy Coil, Hastelloy Alloy G30 Clad Plate, ASME SB 575 UNS N06030 Strips, Hastelloy UNS N06030 Shim Stock

Hastelloy G-30 is an improved version of nickel-chromium-iron-molybdenum-copper alloy G-3. With higher chromium, added cobalt and tungsten, the Hastelloy G-30 Plate shows superior corrosion resistance over most other nickel and iron based alloys in commercial phosphoric acids as well as complex environments containing highly oxidizing acids. The resistance of the DIN 2.4603 Plate to the formation of grain boundary precipitates in the heat-affected zone makes Hastelloy Sheet suitable for use in most chemical process applications in the as-welded condition.

As a result of its high chromium content, Hastelloy G-30 Plate is also very resistant to other oxidizing acids, such as nitric, and mixtures containing nitric acid. It possesses moderate resistance to reducing acids, such as hydrochloric and sulfuric, as a result of its appreciable molybdenum and copper contents. 2.4603 Hastelloy is available in the form of plates, sheets, strips, billets, bars, wires, pipes, tubes, and covered electrodes. Applications include P2O5 evaporator tubes and nitric acid-based, metal pickling hardware.

Nickel Alloy G30 Plate Specification

ASTM B575 UNS N06030 Plate Specification	ASTM B575 UNS N06030, ASME SB575, MSRR, AMS, BS
DIN 2.4603 Plate Sizes (mm)	1000 x 2000, 1220 x 2440, 1500 x 3000, 2000 x 2000, 2000 x 4000
Alloy G30 Plate Thickness	0.1 to 100 mm Thk
2.4603 Hastelloy Plate Width	10-2500mm
Hastelloy Alloy G30 Plate Length	2m, 2.44m, 3m, or as required
Hastelloy UNS N06030 Sheet AMS	AMS
ASTM B575 N06030 Plate Finish	HR, CR, 2B, 2D, BA, NO(8), SATIN
Hastelloy G30 Sheet Hardness	Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Nickel Alloy G30 Plate Stock in form of	Rolling, Shim, Flats, hot-rolled, sheared, Sheet, annealed, cold-rolled, Rolls, soft-annealed, Coils, Tread, Strip, descaled, Foils, Checker, Clad, Blank, Flat, Plate, Circle
Why choose Hitesh Steel	EN 10204/3.1B, Nickel Alloy G30 Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc High special strength, high melt point Excellent corrosive resistance, good thermal resistance Customer support after-sales service Huge Stock, Timely delivery Strict Control from Raw Material to Finished ASTM B575 UNS N06030 plate Free Quote, Inquiry answered within 24 hours
DIN 2.4603 profiling	To provide a full profiling service we use numerous profiling methods including: Laser Plate Cutting Plasma Plate Cutting Oxy-propane Flame Cutting
Export Network	USA, Canada, Australia, UK, Malaysia, Poland, Iran, Italy, Singapore, UAE
Specialized in	Alloy G30 Plates : material 3/16" [5.00 mm] and over in thickness and over 10" [250 mm] in width; 2.4603 Hastelloy Sheet: material under 3/16" [5.00 mm] in thickness and 24" [600 mm] and over in width; Hastelloy Alloy G30 Strip: cold-rolled material under 3/16" [5.00 mm] in thickness and under 24" [600 mm] in width. ASME SB 575 UNS N06030 Clad plate: a composite steel plate made by bonding, etc.
